Shakespeare Style 5241-R VHF Marine
36" LENGTH 3dB
LOW PROFILE END-FED 1/2-WAVE WITH HEAVY-DUTY WHIP

The perfect choice for bass boats, center console fishing boats, or any vessel where compact size is most important. Comes with a heavy-duty stainless steel whip for extra stability at high speeds. Chrome plated brass canister minimizes de-tuning.

• Sealed, tin-plated copper wire coil

• Requires mount with center hole for passage of the supplied 15' RG-58 cable.

• PL-259 connector included

• Stainless steel whip (36")

• Suggested mount: Shakespeare Styles 4187, 4188-S, or 4190 Ratchet Mounts

• Shakespeare Limited Warranty: 2 years

Technical Specifications:

Frequency:	VHF Marine Band
Bandwidth:	7 MHz
SWR:	1.5:1 at 156.8 MHz
Radiation pattern:	Omni-directional
Gain:	3 dB
Max Input (Watts):	50 watts
DC Ground:	YES
Height (feet):	3
Polarization:	Vertical

Manufacturer : Shakespeare
Manufacturer Part No : 5241-R
UPC : 719441100452
